XOI22SC 22 Convertible Insert Blower
XOI22SC 22 Convertible Insert Blower
We might not be able to fulfill your order for the quantity requested
Dimensions
Width: 21 3/16
Height: 12 1/16
Depth: 11 1/8
Color
Features
- Electronic 3 Speed Control + Power Boost
- CCC Code Compliance Control – 395 or 600 CFM*
- Optional ADA Compliant Remote Control
- High Efficiency 3000k LED lights (x2)
- Perimeter Aspiration / Quieter / More Powerful
- Dishwasher Safe Aluminum Mesh Filters
- 5 Minute Delay Shutoff Timer
- 6 Vertical Duct or Recirculating (Kit Sold Separately)
- (Filtered, recirculated air must be returned to the living space)
- Made In Italy
- When CCC™ is enabled the number of fan speeds will be reduced to maximum 3 speeds
Product Description
The center panel of the XOI22/28S provides more than a sleek European appearance, tangential blower and integral sound reduction design minimize background noise.
Specification
| General | |
| Cut-Out Depth (inches) | 10 3/8 |
| Cut-Out Height (in.) | 12 1/4 |
| Cut-Out Width (in.) | 19 5/8 |
| Product Weight (lbs.) | 18.92 |
| ADA Compatible | Yes |
| Prop 65 | Yes |
| Amperage | 3.6 Amps |
| Electrical | 120V - 60Hz - 3.6 Amps |
| Frequency (Hz) | 60 Hz |
| Voltage (volts) | 120 VAC |
| Wattage (watts) | 430 watts |
| Appliance Type | Range Hoods |
| Control Type | Backlit LED |
| Cooktop Lights | Twin LED Lights |
| Mounting Height Above Cooktop | 27 - 32 |
| Controls | Code Compliance Electronic Controls |
